Please read below to fully understand what Android screens are, how they work, and how to get yours!


What are Android screens & what can they do?


If you have iDrive, Android units are a direct replacement for your existing iDrive screen. They're an all in one unit that run completely independently from your original iDrive, and add functions like;

- A separate touchscreen Android interface & device to use and download apps to
- Navigation like Google Maps or Waze
- Bluetooth streaming/bluetooth phone calls
- Reverse cameras
- Front facing dash cam
- Apple CarPlay or Android Auto
- Additional USB devices (hard drives, flash drives, DAB, etc)

These can also be added to cars without iDrive (but must have an AUX in) for the same functionality.

What happens to my current iDrive/radio?


Absolutely nothing - your original iDrive/radio is accessible at all times and remains as part of your car. You can easily switch between the two by either your iDrive controller or via an on screen button on the Android screen.

What's the difference between this & other screens?


As with everything, there are differing versions and variations.

Unfortunately, not everything is created equally, and cheaper Android screens often have lower hardware & software specifications, along with a lack of support.

Ultimately, all Android screens do the same job, just with a different user experience & responsiveness. We only stock the best Android screens available (using the same manufacturer as Avin), and we run them in an own personal vehicles.

If you'd like to see how they work, and have a play around with one, we'll happily show off ours!


General Information

What's included

Assorted items with the Android Screen

    • Main plug & play harness
    • USB harness with two USB type A female sockets
    • External GPS antenna
    • Male to male 3.5mm cable
    • DVR in (single video in from RCA)

Android screen technical specification (PX6)

System Version: 9

CPU: Rockchip PX6 (RK3399) 6 core: Dual Cortex A72 (1.8GHz) + Quad Cortex A53 (1.4GHz) 64 bit

RAM: LPDDR4 4GB

Onboard Storage: EMMC 32/64GB

GPU: Mali-T860

Screen Type & Resolution: 8.8"/10.25" Capacitive touch screen 1280x480 (1920x720 with HD screen)

Bluetooth: BC6 Bluetooth 3.0

Wifi: Realtek RTL8189ETV supporting 802.11BGN 2.4GHZ

GPS: U-BLOX GPS

Audio: Onboard RK616

Dash Cam/DVR: Optional - specific USB 2.0 & generic AV/CVBS supported

Video Playback Formats: Supports H264, MP4, AVI, RMVB, FLV, MKV & more

Audio Playback Formats: Supports MP3, WMA, FLAC, APE, AAC & more

USB: 2 USB cables as standard, supporting up to 64GB flash drives

SD Card: 1 SD card slot, supporting up to 32GB

Phonelink: Airplay (for iOS), Miracast (Android)

Microphone: Build in microphone & supports external microphone

Reversing Camera: Supports OEM reversing camera, along with AV/CVBS camera

PDC: Supports OEM PDC

Finding out what iDrive system you currently have

Guarantee

We provide a 12 month warranty from the date of your invoice which is return to manufacturer providing that the product has normal usage and is in fair condition.

The warranty does not cover the following:

  • Accident, neglect, abuse, or acts of force majeure
  • Unauthorised repair or modification of the products, both hardware and software
  • Failure to install or use the product in accordance with the instruction or use of this product other than for its intended purpose
  • The display screen

Refunds & returns

We offer refunds if the unit is unused in its original packaging. The cost of the shipping back to the manufacturer in China will be taken from the amount paid. Refunds will be initialised through our payment provider when the item has been received by the manufacturer and confirmed passed their internal QA check.

If the unit has been used, a refund/partial refund is at the discretion of the manufacturer dependent on the condition of the item. The cost of the shipping back to the manufacturer in China will be taken from the amount paid. Refunds will be initialised through our payment provider when the item has been received by the manufacturer and confirmed passed their internal QA check.

This is due to the nature & origin of the item, and as it's a custom order unit.

Terms & conditions

Some original CCC screens will require an additional conversion harness for the LVDS cable.

Keep Your Car Safe - KYCS owns all photographic media taken by team members of the services paid for and completed.

By ordering any of our products and/or services, you understand and accept everything outlined.


How easy is it to install?

If you're handy with a screwdriver and trim tools, then you'll be fine! It takes us on average 2 hours to install the screen and reverse camera, including routing all wires and testing the unit.

How long to get these screens?

As we don't keep stock of these units, every order is shipped directly from our manufacturer in China. It usually takes 7-14 days from from payment to us receiving the screen.

Do you supply OS & MCU updates?

Since we work directly with the manufacturer, we can supply bug fixes, OS updates, and supply low level support and diagnostics. We can even enable specialist functions per your request!
